CYCLONE-LC-UNIV
Production Programmer and Debug Probe for ARM® devices and NXP 8/16/32-bit devices
烧写、调试和测试多合一开发工具用于NXP8/16/32 和ARM Cortex 系列芯片

  • 支持芯片系列:
    8-/16-/32-bit devices
    ARM Cortex devices
    NXP: S32
    NXP :
    Kinetis,LPC,Automotive ,iMX,Sensors,Vybrid
      LPC
    Atmel :
    SAMxxx
      Qorivva MPC5xxx
    Cypress:
    CCG2 , FM3 , PRoC-BLE , PSoC®4 , PSoC®5 , PSoC®6
      ColdFire V1
    Infineon:
    XMC
    ColdFire V2/3/4
    NordicSemi:
    nRF51, nRF52
      DSC
    OnBright:
    OB90Rxx
      HC(S)12(X)
    Silergy(Maxim) :
    MAX716xx,AM0x,AM1x
      S12Z
    Silicon Labs :
    EFM32,EFR32,SiM3
      HCS08
    STMicroelectronics:
    STM32
      RS08
    Texas Instruments:
    LM3S,LM4,TM4C12x,SimpleLink
      HC08
    Toshiba:
    TX00,TX03,﹠TX04
      Power MPC5xx/8xx
      ARM Nexus(MAC7xxx)
    STMicro: SPC5,STM8(需搭配 Adapter使用)
功能:
  • USB,串口和以太网口三种计算机接口(Windows 2000/XP/Vista/7/8/10)
  • 16MB内存,最多存储8个程序
  • 4.3”触摸屏,配合start按键进行脱机烧写控制和设置功能
  • 通过继电器控制Cyclone "power-in" a和 "power-out"口的供电。也可通过调试排线向目标板供电
  • Auto-counting serial numbers can be defined as part of the programming image. The Cyclone increments and keeps track of the serial numbers in non-volatile memory.Different images can also share the same set of serial numbers
  • CYCLONE programmers support daisy chaining multiple ARM MCUs for debug or programming
  • ProCryption Security
    -Restrict Image Use
    -Keep Programming Images Secure
    -Encryption is Easy To Implement and Manage
  • SDHC接口支持SDHC卡,可满足更大存储需求
  • 软件和应用:

    创建镜像文件程序

    Cyclone Control Suite

    联机烧写软件:
    -PROG
    -CPROG

    其他软件:
    -Serial Number Creation Utility
    -Barcode Test Generator

CYCLONE-FX-UNIV
Advanced all-in-one program/debug/test interface for many ARM Cortex & NXP 8/16/32-bit devices. Enhanced speed/security/storage.
烧写、调试和测试多合一开发工具用于NXP8/16/32 和ARM Cortex 系列芯片。在烧写速度、加密和存储性能进一步提升。
  • 支持芯片系列:
    8-/16-/32-bit devices
    ARM Cortex devices
    NXP: S32
    NXP :
    Kinetis,LPC,Automotive ,iMX,Sensors,Vybrid
      LPC
    Atmel :
    SAMxxx
      Qorivva MPC5xxx
    Cypress:
    CCG2 , FM3 , PRoC-BLE , PSoC®4 , PSoC®5 , PSoC®6
      ColdFire V1
    Infineon:
    XMC
    ColdFire V2/3/4
    NordicSemi:
    nRF51, nRF52
      DSC
    OnBright:
    OB90Rxx
      HC(S)12(X)
    Silergy(Maxim) :
    MAX716xx,AM0x,AM1x
      S12Z
    Silicon Labs :
    EFM32,EFR32,SiM3
      HCS08
    STMicroelectronics:
    STM32
      RS08
    Texas Instruments:
    LM3S,LM4,TM4C12x,SimpleLink
      HC08
    Toshiba:
    TX00,TX03,﹠TX04
      Power MPC5xx/8xx
      ARM Nexus(MAC7xxx)
    STMicro: SPC5,STM8(需搭配 Adapter使用)
功能:
  • USB,串口和以太网口三种计算机接口(Windows 2000/XP/Vista/7/8/10)
  • 1G内存,对存储的数值没有具体的限制
  • SDHC接口支持SDHC卡,可满足更大存储需求
  • 可与目标板高速通讯,最高可达25Mb/s
  • 4.3”触摸屏具有脱机烧写控制和设置功能
  • 通过继电器控制Cyclone "power-in" a和 "power-out"口的供电。也可通过调试排线向目标板供电
  • Auto-counting serial numbers can be defined as part of the programming image. The Cyclone increments and keeps track of the serial number for both internal images as well as SDCard images.
  • CYCLONE programmers support daisy chaining multiple ARM MCUs for debug or programming.
  • Dynamic Data:
    The CYCLONE FX can accept dynamic data provided by a PC for each programming operation which is programmed along with the data contained in a programming image.
  • ProCryption Security
    -Restrict Image Use
    -Keep Programming Images Secure
    -Encryption is Easy To Implement and Manage
  • 扩展加密:
    - 烧写控制限制
    - 数据区域限制镜像文件烧写
    - 防篡改技术
    - 内存数据保护和加密
  • 软件和应用:

    创建镜像文件程序

    Cyclone Control Suite

    联机烧写软件:
    -PROG
    -CPROG

    其他软件:
    -Serial Number Creation Utility
    -Barcode Test Generator

LIC-CYC-CTRL-ADV
Activates Advanced Automated Programming features on Cyclone Programmer

  • Add/Remove/Update many images in the Cyclone (Console, SDK, GUI)
  • Simultaneously (Gang) Control of multiple Cyclones via the USB, Serial, or Ethernet connections
  • Program (and Read) Dynamic Data in addition to fixed image data
  • Remote Display Access
  • Read/write Cyclone properties
  • Read Image and target Properties and Status
  • Compare images against a SAP file

LIC-CYC-SDCARD
SDHC port activation for external storage on Cyclone Programmer

  • 安装在Cyclone Programmer上激活SDHC端口
注:仅包含license,SDHC card 需单独购买
SDCARD
16 GB Encryped SDHC Flash Card for Cyclone
  • Easily be moved from Cyclone to Cyclone.
  • 16GB Encryptyed Cyclone SDHC Card is pre-formatted, tested, and certified to work with CYCLONE programmers.
注:需配套SDHC port License使用
LIC-CYC-PROCRYPTION
Cyclone LC Protected and Encrypted SAP Image Activation License
    It allows users to place protection on their programming images to restrict image use by date range or number of programs allowed. It also allows users to create RSA/AES encrypted programming images that use their own uniquely generated ImageKey. These images may only be used to program targets on Cyclones that are pre-configured with this unique ImageKey. This license keeps the user securely in control of both their IP and the programming process.
  • Restrict Image Use
  • Keep Programming Images Secure
  • Encryption is Easy To Implement and Manage

Cyclone Automated Control Package
Cyclone Automated Control Package with Dynamic Link Library (DLL)

P&E Cyclone PRO,P&E Cyclone MAX多机控制程序包,带有DLL动态联接库

CompactFlash Activation License + Flash Card
Activates the CompactFlash feature of the Manage Images utility

激活CompactFlash程序映像管理功能

通过CompactFlash Interface 可以实现大容量程序烧写,也可将更多个程序映像存储到CompactFlash Card 中。

  • 存储大容量程序或更多个程序映像
  • 程序映像的增加adding,删除deleting和已存储的程序映像升级updating
  • 管理存储在PE Cyclone PRO 或 PE Cyclone MAX 中程序映像
  • 2GB CF 卡 CompactFlash card

CAB_RIBBON_16_PIN
16-Pin Ribbon Cable for 68HC08 (MON08)

16-Pin 用于68HC08 (MON08)的带状电缆





Cyclone_Pro_Power_CABLES
可替换的三套电力电缆(用于Cyclone Pro)

尺寸:

其中两套:一端2.5mm x 5.5mm,另一端镀锡铅插头

其中一套: 两端2.5mm x 5.5mm的插头

USB-ML-MON08 (已停产)
P&E USB MON08 Multilink Cable for the 68HC08 MON08

P&E USB Multilink MON08交互式转换接口(USB)

Cyclone PRO (已停产)
Hardware Debug Interface and Stand-Alone Programmer for HC08, HCS08, RS08, S12Z ,ColdFire V1, and HC(S)12(X)

P&E Multilink Cable硬件调试交互式转换接口和脱机烧写设备

CASM08Z
68HC08 Command-Line Assembler

68HC08 汇编工具

通过PE Multilink Cable 转换接口(PE USB-ML-MON08,Cyclone Pro),在线烧写内外闪存软件。

基于Window98 /ME/NT/2000/XP界面的汇编工具

  • 支持宏 (Macro Support)
  • S19 目标文件 (S19 objects)
  • 支持条件汇编 (Conditional Assembly)
  • 可包含外部文件 (Include Files)
  • 带有计数器列表控制( Full listing control with cycle counter)

CPROG08SZ
68HC08 Command-Line Programming Software

68HC08 烧写软件

通过P&E Multilink Cable转换接口(P&E USB-ML-MON08,Cyclone Pro,连接到目标板16 针MON08接口上),在线烧写内外闪存软件。功能:

  • BM Blank check module
  • BR Blank check range
  • EB Erase byte range
  • EW Erase word range
  • EM Erase module
  • PB Program bytes
  • PW Program words
  • PM Program module
  • CM Choose module .08P file
  • VM Verify module
  • VR Verify range
  • VC Verify module CRC-8
  • UM Upload module

ICS08_ALL
Complete P&E ICS08 Software

全套 P&E ICS08 软件

  • WinIDE08集成开发环境(IDE)
  • ICD08SZ 在线调试
  • PROG08SZ交互式MON08烧写软件
  • ICS08ICS full Chip Simulator 仿真
  • ICS08 和 ICD08SZ 原带码汇编调试采用P&E MAP 文件格式及ELF/DWARF v2.0 或 ImageCraft v1.调试文件格式的C原代码调试。

SDEV908GZ60
SDEV908GZ60 Development Board

SDEV908GZ60开发板

SDEV908JL8
SDEV908JL8 Development Board

SDEV908JL8 开发板

SDEV908MR32
SDEV908MR32 Development Board

SDEV908MR32 开发板

SDEV908QY4
SDEV908QY4 Development Board

SDEV908QY4 开发板

WINIDE08Z
68HC08 Windows Integrated Development Environment

68HC08集成开发环境

它提供在一个编程环境中由一个热键执行外部程序如汇编语言、C编译器、调试器和Flash 编程器。它同时安装CASM08Z汇编器.

其编辑特点为:

  • 结构可重组
  • 允许执行外部程序
  • 在线帮助

汇编器特点:

  • 支持宏汇编
  • 目标文件可为S19, HEX, IEEE695格式
  • 支持条件汇编
  • 可包含外部文件
  • 带有计数器列表控制
